LGMG Mine Truck 2026 – High voltage box harness assy – K6200-2762001471.S1A
Category: 2026 > Mine Truck > RTH100 > R1000Y3A0A241
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Z-bracket 60*33*20 | 27620010511 | 1 |
| 2 | Bolt GB5783-M10*35flZnyc-8.8-480 | 4011010727 | 20 |
| 3 | Nut GB6185.1-M10flZnyc-8-480 | 4013010292 | 37 |
| 4 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 86 |
| 5 | Grommet 83*59*16 | 27620009171 | 1 |
| 6 | L-bracket 70*35*25 | 27620008831 | 5 |
| 7 | Bolt GB5783-M10*20EpZn-8.8 | 4011000081 | 1 |
| 8 | Double sack wedge lock washer HF10 | 4190708409 | 1 |
| 9 | Washer GB97.1-10EpZn-300HV | 4015000162 | 1 |
| 10 | Washer GB862.2-10-65Mn | 4015010586 | 1 |
| 11 | Microvast-branded bdu harness assy | 27200226001 | 1 |
| 12 | Bolt GB5783-M8*20EpZn-8.8 | 4011000105 | 1 |
| 13 | Double sack wedge lock washer HF8 | 4190708408 | 1 |
| 14 | Washer GB97.1-8EpZn-300HV | 4015000072 | 1 |
| 15 | Ground wire p50-10*10*800-1.8 | 27620007401 | 1 |
| 16 | Bolt GB5782-M10*65flZnyc-8.8-480 | 4011010729 | 2 |
| 17 | Cable tie 14400342 | 4130703098 | 11 |
| 18 | Bolt GB5782-M10*85flZnyc-8.8-480 | 4011011218 | 1 |
| 19 | Pipe clamp 3*25-120*35*17 | 27620009461 | 12 |
| 20 | Bracket wldmt | 27620012361 | 1 |
| 21 | Bracket 170*65*45 | 27620009421 | 6 |
| 22 | Battery communication harness 2920 | 27620012401 | 1 |
| 23 | Bolt GB5783-M10*30flznyc-8.8-480 | 4011010707 | 10 |
| 24 | L-bracket 150*46*25 | 27620014151 | 2 |
| 25 | Bolt gb5782-m10*90flznyc-8.8-480 | 4011011873 | 2 |
| 26 | Grommet 133*109*16 | 27620009441 | 1 |
| 27 | Grommet 128*104*16 | 27620009431 | 1 |
| 28 | Bolt GB5783-M10*60flZnyc-8.8-480 | 4011010977 | 10 |
| 29 | Tube bank plate 100*35*17 | 27620003921 | 4 |
| 30 | Bolt GB5783-M10*20flZnyc-8.8-480 | 4011010748 | 4 |
| 31 | L-bracket 60*60*35 | 27620015251 | 1 |
| 32 | Bracket wldmt | 27620010951 | 3 |
| 33 | Battery communication harness 3250 | 27620015451 | 1 |
| 34 | High voltage harness between battery modules 1100 | 27620015411 | 1 |
| 35 | High voltage harness between battery boxes 1455 | 27620008422 | 1 |
| 36 | High voltage harness between battery modules 1820 | 27620015421 | 1 |
| 37 | High voltage harness between battery modules 2040 | 27620015441 | 1 |
| 38 | High volt wire between battery boxes 2260 | 27620005153 | 1 |
| 39 | High voltage harness between battery boxes 2440 | 27620008072 | 1 |
