LGMG Off-Highway Dump Truck 2024 – Accessory assembly – M1601-2716013209.S1F
Category: 2024 > Off-Highway Dump Truck > MT96L > M096LW3A0M315
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Hose F351TCCACF222212-550 | 4120711553 | 1 |
| 2 | Hose F351TCCACA222212-1360 | 4120712469 | 1 |
| 3 | Oil pipe welding 02 | 27160134211 | 1 |
| 4 | Hose F351TCCACF222212-430-FS | 4120711480-001 | 1 |
| 5 | Combination joint LGB143-03019 | 4041001262 | 1 |
| 6 | Pipe | 27160115692 | 1 |
| 7 | Plug 4MN-18WD | 4120703163 | 1 |
| 8 | Guard | 27160106272 | 1 |
| 9 | Butterfly spring clamp φ51-φ73 | 4190708162 | 2 |
| 10 | Oil return hose | 27160131841 | 1 |
| 11 | Pipe welding | 27160132131 | 1 |
| 12 | Steel pipe support assembly | 27160133611 | 2 |
| 13 | Pipe | 27160113252 | 1 |
| 14 | Air hose 2000 | 27160137791 | 1 |
| 15 | JOINT LGB143-03625 | 4041001211 | 1 |
| 16 | HOSE | 2716011254-013 | 1 |
| 17 | PIPE | 27400104391 | 1 |
