LGMG Off-Highway Dump Truck 2024 – Bracket assy 01 – H1501-2715013329.S1A
Category: 2024 > Off-Highway Dump Truck > MT116H > M116HY3A0M033
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bracket weldment 02 | 27150133321 | 1 |
| 2 | Clamp | 27160130601 | 2 |
| 3 | Plate 110*4*5 | 27150133301 | 1 |
| 4 | Bolt GB5782-M10*130EpZn-8.8 | 4011000535 | 2 |
| 5 | Washer GB96.1-10EpZn-300HV | 4015000197 | 3 |
| 6 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 3 |
| 7 | Bolt GB5782-M10*55EpZn-8.8 | 4011000049 | 1 |
