LGMG Off-Highway Dump Truck 2024 – Exhaust and heating sys – A2401-2724011352.S1A
Category: 2024 > Off-Highway Dump Truck > MT106H > M106HW3E0M003
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Nut GB6170-M8EpZn-8 | 4013000033 | 12 |
| 2 | Washer GB96.1-8EpZn-300HV | 4015000256 | 6 |
| 3 | Muffler | 4110703641 | 1 |
| 4 | Plate | 27010110661 | 1 |
| 5 | Bolt GB5783-M12*55EpZn-8.8 | 4011000254 | 4 |
| 6 | Plate | 27010110671 | 1 |
| 7 | Exhaust brake butterfly valve | 4110000157 | 1 |
| 8 | Upr exhaust pipe wldmt | 27240113531 | 1 |
| 9 | Upr exhaust pipe insulation cotton LG24-GRM01 | 4110704970 | 1 |
| 10 | PLATE | 27240102051 | 3 |
| 11 | Lwr exhaust pipe wldmt | 27240113541 | 1 |
| 12 | Support welding | 27240109101 | 1 |
| 13 | Bolt GB16674.1-M10*65EpZn-8.8 | 4011000230 | 2 |
| 14 | Fixed bracket weldment | 27240110921 | 1 |
| 15 | Bolt GB16674.1-M10*50EpZn-8.8 | 4011000309 | 2 |
| 16 | Lwr exhaust pipe heat insulation GRM-LG-D130-841-W1 | 4190711222 | 1 |
| 17 | Bolt GB16674-M12*120EpZn-8.8 | 4011011420 | 4 |
| 18 | Washer GB97.1-12EpZn-300HV | 4015000168 | 4 |
| 19 | Nut GB6170-M12EpZn-8 | 4013000011 | 8 |
| 20 | Exhaust pipe insulation cotton LG24-GR-003 | 4110705912 | 1 |
| 21 | Turbocharger insulation cotton LG24-GR-002 | 4110705911 | 1 |
| 22 | Exhaust conversion box | 4190003584 | 1 |
| 23 | Nut GB6177.1-M10flZnyc-8-480 | 4013010375 | 2 |
| 24 | Plate | 27010110711 | 3 |
| 25 | Clamp | 4110000768 | 3 |
| 26 | Bolt GB5782-M10*75EpZn-8.8 | 4011000052 | 3 |
| 27 | Nut GB6170-M10EpZn-8 | 4013000007 | 15 |
| 28 | Bolt GB5783-M12*40EpZn-8.8 | 4011000091 | 4 |
| 29 | Washer GB96.1-12EpZn-300HV | 4015000186 | 12 |
| 30 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 8 |
| 31 | TENSIONING LEVER | 27010101611 | 3 |
