LGMG AT40 2025 – Hill-start assist valve – J1001-2710013352.S1B
Category: 2025 > AT40 > A0400W3M0A108
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB97.1-16flZnyc-300HV-480 | 4015010287 | 2 |
| 2 | Bolt GB16674.1-M8*20flZnyc-8.8-480 | 4011010966 | 3 |
| 3 | Bdsv valve hic101000685 | 4120714529 | 1 |
| 4 | Bracket wldmt | 27100139311 | 1 |
| 5 | Plug VSTI3/8ED | 4120704862 | 1 |
| 6 | Joint GE12LR1/4EDOMDCF | 4120704913 | 4 |
| 7 | Straight joint 1CB-22-06WD | 4120005156 | 1 |
| 8 | Joint 1CB-18-06WD | 4120001499 | 1 |
| 9 | Joint GE10LREDOMDCF | 4120001188 | 1 |
| 10 | Bolt GB5782-M16*70flZnyc-10.9-480 | 4011010483 | 2 |
| 11 | Nut GB6170-M16flZnyc-10-480 | 4013010235 | 2 |
