LGMG CMT106 2025 – Transmission assembly – C0501-2705011534.S1B
Category: 2025 > CMT106 > C1060W3E0A125
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Flexible disc mounting ring TD005137 | 4110705212 | 1 |
| 2 | Flywheel housing transition ring TD005103 | 4110705213 | 1 |
| 3 | Stud GB900-A M10*60EpZn-8.8 | 4012010111 | 12 |
| 4 | Washer GB97.1-10-300HV | 4015000322 | 12 |
| 5 | Nut GB6170-M10EpZn-8 | 4013000007 | 12 |
| 6 | Pressure switch 29511309（10psi） | 4110702825 | 2 |
| 7 | Retarder mod joystick 29570374 | 4110707935 | 1 |
| 8 | Oil plug IH000002 | 4110702840 | 1 |
| 9 | O-ring 37.47*3（IH004104） | 4110702846 | 1 |
| 10 | Bolt GB5783-M6*25EpZn-8.8 | 4011000276 | 4 |
| 11 | Transmission box 4800wbd_pr（e034238）32403456 | 4110707936 | 1 |
| 12 | Washer GB97.1-6EpZn-300HV | 4015000207 | 4 |
| 13 | Nut GB6170-M6EpZn-8 | 4013000028 | 4 |
| 14 | TCM 73CR0XBN | 4110706719 | 1 |
| 15 | Lever selector（RH Hand）29557835 | 4110702822 | 1 |
| 16 | Bolt M8*1.25*25 | 4110704943 | 24 |
| 17 | Connecting flange TD005281 | 4110705211 | 1 |
| 18 | Shim TD005109 | 4110705210 | 1 |
| 19 | Flexible disc assy 29514832 | 4110702835 | 1 |
| 20 | Flexible disc 29514833 | 4110702834 | 3 |
| 21 | Flywheel connecting bolt 11505501 | 4110702832 | 24 |
| 22 | Retarder control MOD 29506474 | 4110706007 | 1 |
