LGMG CMT106 2025 – Water radiator assy – A0301-2703017392.S1A
Category: 2025 > CMT106 > C1060Y3E0A102
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Exhaust pipe strap | 27240102332 | 2 |
| 2 | Washer GB96.1-10EpZn-300HV | 4015000197 | 8 |
| 3 | Nut GB6170-M10EpZn-8 | 4013000007 | 8 |
| 4 | Plug 28*4 | 27030164971 | 1 |
| 5 | Nut GB6170-M12EpZn-8 | 4013000011 | 6 |
| 6 | Intercooler air outlet hose | 27030172121 | 1 |
| 7 | Engine water inlet hose 87*6 | 27030173961 | 1 |
| 8 | Bolt GB5783-M10*90EpZn-12.9 | 4011011013 | 4 |
| 9 | Washer GB97.1-10EpZn-300HV | 4015000162 | 4 |
| 10 | Nut GB6185.1-M10EpZn-12 | 4013010567 | 4 |
| 11 | Radiator LG03-SRQ-002 | 4110707385 | 1 |
| 12 | Plate | 27030109021 | 2 |
| 13 | Radiator shock absorber assy | 4110001445 | 2 |
| 14 | Lh bracket wldmt | 27030173491 | 1 |
| 15 | Bolt GB5783-M16*60EpZn-8.8 | 4011000594 | 8 |
| 16 | Washer GB97.1-16EpZn-300HV | 4015000181 | 8 |
| 17 | Nut GB6185.1-M16EpZn-8 | 4013010122 | 8 |
| 18 | Bolt GB5783-M12*35EpZn-8.8 | 4011000090 | 2 |
| 19 | Washer GB96.1-12EpZn-300HV | 4015000186 | 2 |
| 20 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 2 |
| 21 | Plate | 27030124581 | 2 |
| 22 | Engine water outlet hose 87*6 | 27030168401 | 1 |
| 23 | Radiator bar | 4110001451 | 2 |
| 24 | Hose clamp JB8870-D32 | 4017000011 | 1 |
| 25 | Bracket 160*150*80 | 27030173531 | 2 |
| 26 | Bolt GB5782-M10*55EpZn-8.8 | 4011000049 | 4 |
| 27 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 4 |
| 28 | Plate | 27030109731 | 2 |
| 29 | Bolt GB5782-M14*85EpZn-8.8 | 4011010630 | 2 |
| 30 | Nut GB6185.1-M14EpZn-8 | 4013010121 | 2 |
| 31 | Rh bracket wldmt | 27030173511 | 1 |
| 32 | Bolt GB16674.1-M10*25EpZn-8.8 | 4011000474 | 4 |
| 33 | Butterfly spring clamp φ70-φ92 | 4190708164 | 4 |
| 34 | Hose 112*6*150 | 27030173541 | 1 |
| 35 | Plate 455*220*8 | 27030173941 | 1 |
| 36 | Bracket 395*220*86 | 27030173581 | 1 |
| 37 | Pipe 100*1.5 | 27030173951 | 1 |
| 38 | Butterfly spring clamp φ93-φ118 | 4190708166 | 6 |
| 39 | Hose 112*6 | 27030173551 | 1 |
