LGMG CMT66 2025 – Fan guide assy – I3900-2739010082
Category: 2025 > CMT66 > C0660W3E0A026
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Wind deflector | 27390100831 | 1 |
| 2 | Nut GB6170-M12EpZn-8 | 4013000011 | 9 |
| 3 | Washer GB96.1-12EpZn-300HV | 4015000186 | 9 |
| 4 | Bolt GB5783-M12*25EpZn-8.8 | 4011000197 | 7 |
| 5 | Rubber mat | 27390100851 | 1 |
| 6 | Bolt GB5783-M12*50EpZn-8.8 | 4011000092 | 2 |
| 7 | Plate | 27390100841 | 2 |
