LGMG CMT66 2025 – Rear leaf spring assy – G1200-2712018040.S1A
Category: 2025 > CMT66 > C0660W3E0A025
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | RR leaf spring assy LG12-HBH-25*100 | 4110703105 | 1 |
| 2 | Rear leaf spring pressplate | 27120116971 | 1 |
| 3 | Plate | 27120117251 | 2 |
| 4 | Guide pin | 27120103821 | 2 |
| 5 | Bolt | 27120117261 | 8 |
| 6 | Self-locking nut with the shoulder | 27120103611 | 8 |
| 7 | Washer 24 | 27120118761 | 8 |
