LGMG CMT66A 2025 – ASM-battery box mounting assy – J1001-2710012084.S1A
Category: 2025 > CMT66A > C066AW3E0A023
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Drain valve | 4120000200 | 2 |
| 2 | Hose clamp φ315-φ320 | 4120001542 | 4 |
| 3 | Battery box assy MT95 | 4190002270 | 1 |
| 4 | Bolt GB5783-M12*30EpZn-8.8 | 4011000089 | 4 |
| 5 | Air reservoir bracket | 27100108131 | 2 |
| 6 | Nut GB6170-M12EpZn-8 | 4013000011 | 4 |
| 7 | Washer GB97.1-12EpZn-300HV | 4015000168 | 4 |
| 8 | Nut GB6185.1-M16EpZn-10 | 4013010136 | 2 |
| 9 | Bolt GB5783-M16*40EpZn-10.9 | 4011000545 | 2 |
| 10 | Washer GB97.1-16EpZn-300HV | 4015000181 | 2 |
| 11 | Air reservoir 50L | 4120001543 | 2 |
