LGMG CMT66A 2025 – Fan guide assy – L3900-2739010322
Category: 2025 > CMT66A > C066AW3E0A012
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Rubber mat | 27390100201 | 2 |
| 2 | Bolt GB5783-M16*55EpZn-8.8 | 4011000612 | 2 |
| 3 | Nut GB6185.2-M16*1.5-12 | 4013010222 | 2 |
| 4 | Plate | 27390103271 | 2 |
| 5 | Nut GB6170-M10EpZn-8 | 4013000007 | 10 |
| 6 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 6 |
| 7 | Washer GB96.1-10EpZn-300HV | 4015000197 | 8 |
| 8 | Plate | 27390103261 | 2 |
| 9 | Plate | 27390103231 | 1 |
| 10 | U SHAP BOLT | 27390100171 | 2 |
