LGMG Hydraulic excavator 2025 – Servo system – F1201-2612020165.S1D
Category: 2025 > Hydraulic excavator > ME130-1 > E13000P3A005
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Straight joint LGB177-21822 | 4041010957 | 2 |
| 2 | RECT ring LGB176-12124 | 4041003074 | 2 |
| 3 | Hose f481caca121206-1050 | 4120714324-001 | 1 |
| 4 | Hose f481cacf121206-1050 | 4120704419-010 | 1 |
| 5 | Tee LGB175-0181818 | 4041010961 | 2 |
| 6 | Reducing joint RED12/08LOMDCF | 4120001299 | 2 |
| 7 | Combination joint LGB143-01406 | 4041001047 | 1 |
| 8 | Nipple | 26120014431 | 2 |
| 9 | Filtering joint g1/4-m18 | 26120204351 | 2 |
| 10 | O-ring | 4190707657 | 2 |
| 11 | Pipe clamp LGB169-A20*12.5 | 4041010363 | 4 |
| 12 | Bolt GB16674.1-M12*20flZnyc-8.8-480 | 4011011106 | 4 |
