LGMG Hydraulic excavator 2026 – Rear wall interior assy CABCN4 – L2902-2629020393.S1A
Category: 2026 > Hydraulic excavator > ME109 > E10900P3A000
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB16674.1-M6*16flZnyc-8.8-480 | 4011010735 | 2 |
| 2 | Bolt GB16674.1-M8*20flZnyc-8.8-480 | 4011010966 | 2 |
| 3 | Bolt GB16674.1-M8*12flZnyc-8.8-480 | 4011011062 | 2 |
| 4 | Hose clamp JB8870-D60 | 4017000007 | 1 |
| 5 | RH RR circumference assy CABCN4 | 4190707819 | 1 |
| 6 | LH RR wall assy CABCN4 | 4190707820 | 1 |
| 7 | RR wall lower guard assy CABCN4 | 4190707821 | 1 |
| 8 | Cover plate CABCN4 | 4190707823 | 1 |
| 9 | Beam CABCN4 | 4190707817 | 1 |
| 10 | Bracket CABCN4 | 4190707818 | 1 |
| 11 | Cushion CABCN4 | 4190707822 | 1 |
| 12 | Knob switch CABCN4 | 4190707824 | 5 |
| 13 | 螺栓GB16674.1-M10*25flZnyc-8.8-480 | 4011001299 | 4 |
