LGMG Hydraulic excavator 2026 – Working lamp mounting – P4302-2643020188.S1A
Category: 2026 > Hydraulic excavator > ME109 > E10900P3A000
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB16674.1-M8*16EpZn-8.8 | 4011000461 | 1 |
| 2 | Bolt GB16674.1-M10*25flZnyc-8.8-480 | 4011011015 | 6 |
| 3 | Nut GB6170-M10flZnyc-8-480 | 4013010289 | 6 |
| 4 | Bolt GB16674.1-M8*25flZnyc-8.8-480 | 4011010994 | 2 |
| 5 | Plate | 26430201491 | 1 |
| 6 | Wire | 26430201782 | 1 |
| 7 | Headlamp mounting bracket | 26430201891 | 1 |
| 8 | Line | 26430201902 | 1 |
| 9 | LED WORKLAMP ASS‘Y’ | 26470100571 | 4 |
| 10 | No longer used | 4011010857 | 2 |
| 11 | Bolt GB5783-M8*20-8.8 | 4011000723 | 1 |
| 12 | Washer GB96.1-8EpZn-300HV | 4015000256 | 1 |
| 13 | Pipe clamp LGB169-A10*10 | 4041010597 | 5 |
