LGMG LGMG50T 2025 – Bracket assy 06 – H1501-2715014654.S1A
Category: 2025 > LGMG50T > M0500W2E0M203
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bracket 200*40*40 | 27150146551 | 1 |
| 2 | Oil suction pipe clamp 76*30*29 | 27150137202 | 2 |
| 3 | Cover plate48*30*3 | 27150137211 | 1 |
| 4 | Cable tie HS-J117 | 4130704969 | 2 |
| 5 | Bolt GB5783-M10*90EpZn-8.8 | 4011000956 | 2 |
| 6 | Nut GB6170-M10EpZn-8 | 4013000007 | 3 |
| 7 | Washer GB97.1-10EpZn-300HV | 4015000162 | 3 |
| 8 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 1 |
