LGMG Mine Truck 2026 – Air compressor assy – J1001-2710014317.S1D
Category: 2026 > Mine Truck > MTH126M > C1260Y3A0A206
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB16674.1-M10*35flZnyc-8.8-480 | 4011011104 | 3 |
| 2 | Nut GB6170-M10flZnyc-8-480 | 4013010289 | 1 |
| 3 | Washer GB96.1-10flZnyc-300HV-480 | 4015010278 | 1 |
| 4 | Bracket 165*60*30 | 27100142381 | 1 |
| 5 | Dryer assy | 27100147231 | 1 |
| 6 | Bolt gb16674.1-m10*45flznyc-8.8-480 | 4011011465 | 4 |
| 7 | Nut GB6177.1-M10flZnyc-8-480 | 4013010375 | 9 |
| 8 | Bracket 400*82*40 | 27100141612 | 2 |
| 9 | Bolt GB16674.1-M10*40flZnyc-8.8-480 | 4011011086 | 2 |
| 10 | Bolt gb5789-m14*60flznyc-8.8-480 | 4011011981 | 8 |
| 11 | Air intake hose assy | 27100143201 | 1 |
| 12 | Nut gb6177.1-m14flznyc-8-480 | 4013010623 | 8 |
| 13 | Air compressor bracket wldmt | 27100141883 | 2 |
| 14 | Plate 384*50*8 | 27100138701 | 1 |
| 15 | L bracket 100*25*70 | 27150129891 | 1 |
| 16 | Cable tie HS-J117 | 4130704969 | 1 |
| 17 | Bolt GB16674.1-M10*30flZnyc-8.8-480 | 4011010712 | 1 |
| 18 | Air compressor QXAC4P/4G686-4kW | 4120711497 | 1 |
| 19 | Bolt GB16674.1-M12*30flZnyc-8.8-480 | 4011010713 | 4 |
| 20 | Washer GB97.1-12flZnyc-300HV-480 | 4015010340 | 4 |
| 21 | Combination joint LGB143-02213 | 4041001156 | 1 |
| 22 | Combination joint LGB143-12213 | 4041001218 | 1 |
| 23 | Steel braided hose 470 (high resilence) | 27100155371 | 1 |
| 24 | Spiral pipe assy | 27100144941 | 1 |
| 25 | Steel braided hose 340 (high resilence) | 27100145031 | 1 |
| 26 | Bolt GB16674.1-M6*50flZnyc-8.8-480 | 4011010873 | 2 |
| 27 | Nut GB6177.1-M6flZnyc-8-480 | 4013010388 | 2 |
| 28 | Tube clamp TLPG12-218 | 4120708228 | 1 |
| 29 | Pipe weldment 02 | 27100142371 | 1 |
