LGMG Mine Truck 2026 – Gear pump assy – M1501-2715015365.S1B
Category: 2026 > Mine Truck > MTH126M > C1260Y3A0A206
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bracket wldmt 01 | 27150153671 | 1 |
| 2 | Nut gb6177.1-m12flznyc-12-480 | 4013010622 | 4 |
| 3 | Pump coupling | 4120001055 | 1 |
| 4 | Bolt GB5783-M10*35flZnyc-8.8-480 | 4011010727 | 4 |
| 5 | Nut GB6177.1-M10flZnyc-8-480 | 4013010375 | 8 |
| 6 | Power takeoff transmisson shaft LG16-CDZ01-235 | 4110706565 | 1 |
| 7 | Bolt GB5783-M10*30flznyc-8.8-480 | 4011010707 | 4 |
| 8 | Bolt GB16674.1-M8*65flZnyc-8.8-480 | 4011011203 | 1 |
| 9 | Nut gb6187.1-m8flznyc-8-480 | 4013010627 | 1 |
| 10 | Bolt gb5789-m16*1.5*80flznyc-12.9-480 | 4011011948 | 3 |
| 11 | 90° fitting ew30somdcf | 4120716153 | 1 |
| 12 | Nut gb6187.2-m16*1.5flznyc-12-480 | 4013010635 | 5 |
| 13 | Bolt gb5789-m16*1.5*90flznyc-12.9-480 | 4011011949 | 2 |
| 14 | Fitting gfs35/30s/10omdcf | 4120718594 | 1 |
| 15 | Flange fhs35/10cf | 4120715837 | 2 |
| 16 | O-ring GB3452.1-37.5*3.55G | 4030000029 | 1 |
| 17 | Gear pump cbgje-f3160-bf3h | 4120715855 | 1 |
| 18 | Screw GB70.1-M10*30flZnyc-10.9-480 | 4014010287 | 4 |
| 19 | Split flange sae fhs310cfx | 4120715835 | 2 |
| 20 | Pipe wldmt 01 | 27160157351 | 1 |
| 21 | Screw GB70.1-M12*35flZnyc-10.9-480 | 4014010282 | 4 |
