LGMG Mine Truck 2026 – Hood installation – L3868-2736384580.S1A
Category: 2026 > Mine Truck > RTH100 > R1000Y3A0A240
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Pin GB882-B24*90EpZn-35 | 4016010151 | 2 |
| 2 | Washer GB97.1-24flZnyc-300HV-480 | 4015010364 | 2 |
| 3 | Lock chain DK636-1（ShengJiu） | 4190704689 | 2 |
| 4 | Bolt GB5783-M8*30flznyc-8.8-480 | 4011010708 | 8 |
| 5 | Nut GB6185.1-M8flZnyc-8-480 | 4013010314 | 12 |
| 6 | Plate | 27360131911 | 2 |
| 7 | Bolt GB5782-M8*85flZnyc-8.8-480 | 4011010968 | 4 |
| 8 | Nut GB6170-M14flZnyc-8-480 | 4013010366 | 4 |
| 9 | Washer GB96.1-14flZnyc-300HV-480 | 4015010371 | 4 |
| 10 | Engine hood limit rod wldmt | 27360204301 | 2 |
| 11 | PLATE | 27360117151 | 1 |
| 12 | Pin 43.5*16*7 | 27360166591 | 4 |
| 13 | Pin GB91-3.2*26flZnyc-Q235A-480 | 4016010138 | 4 |
| 14 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 3 |
| 15 | Cover | 27360127271 | 1 |
| 16 | Lwr protective mesh wldmt | 27360204321 | 1 |
| 17 | Cover plate wldmt | 27360219501 | 1 |
| 18 | Protective mesh plate ii | 27360197201 | 1 |
| 19 | Protective mesh plate | 27360197211 | 2 |
| 20 | Plate | 27360139441 | 3 |
| 21 | Hood wldmt | 27360223531 | 1 |
| 22 | Bolt GB5783-M8*16flznyc-8.8-480 | 4011010970 | 22 |
| 23 | Washer GB96.1-8flZnyc-300HV-480 | 4015010289 | 46 |
| 24 | Pin GB91-5*40flZnyc-Q235A-480 | 4016010133 | 2 |
