LGMG Mine Truck Mine Truck – Exhaust system – A0100-2701010763
Category: Mine Truck > Mine Truck > M0860WE00
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Nut GB6170-M8EpZn-8 | 4013000033 | 16 |
| 2 | Washer GB97.1-12EpZn-300HV | 4015000168 | 4 |
| 3 | Bolt GB5783-M12*30EpZn-8.8 | 4011000089 | 2 |
| 4 | Buffer box assembly | 4110000737 | 1 |
| 5 | Left bracket | 4110000280 | 1 |
| 6 | Right bracket | 4110000281 | 1 |
| 7 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 2 |
| 8 | Connecting pipe | 27010104802 | 1 |
| 9 | Shim WG9731540079 | 4190000165 | 1 |
| 10 | Clamp | 4190000164 | 2 |
| 11 | Bolt GB5783-M8*50EpZn-8.8 | 4011000702 | 6 |
| 12 | Exhaust butterfly valve assembly | 4120000132 | 1 |
| 13 | Shim WG9719540019 | 4190000167 | 1 |
| 14 | Clamp | 4190000166 | 4 |
| 15 | Bolt GB5783-M8*40EpZn-8.8 | 4011000299 | 8 |
| 16 | Exhaust pipe II assembly | 4110000733 | 1 |
