LGMG Mine Truck Mine Truck – Front oil spring – G1200-2712012114
Category: Mine Truck > Mine Truck > M086HWBY0
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Nut GB6185.1-M20flZnyc-12-480 | 4013010256 | 24 |
| 2 | Plate | 27120119581 | 2 |
| 3 | Adjustment gasket | 27120119181 | 2 |
| 4 | Adjustment gasket | 27120119191 | 2 |
| 5 | Surpport | 27120121161 | 2 |
| 6 | Frame bottom limit block | 4110002085 | 2 |
| 7 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 8 |
| 8 | Washer GB97.1-10EpZn-300HV | 4015000162 | 8 |
| 9 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 8 |
| 10 | Bolt GB5786-M14*1.5*35flZnyc-12.9-480 | 4011010578 | 4 |
| 11 | The limiting block supporting frame | 27120120661 | 2 |
| 12 | Washer | 27120114921 | 4 |
| 13 | Dust ring 70 | 4110000879 | 8 |
| 14 | Sleeve | 27120108441 | 8 |
| 15 | Pin | 27120119151 | 4 |
| 16 | Bolt GB5786-M16*1.5*55flZnyc-12.9-480 | 4011010640 | 8 |
| 17 | Washer GB97.1-16EpZn-300HV | 4015000181 | 8 |
| 18 | Nut GB6185.2-M16*1.5flZnyc-12-480 | 4013010255 | 8 |
| 19 | Washer20 | 27120121181 | 4 |
| 20 | Oil spring upper bracke | 27120121151 | 2 |
| 21 | Front spring assembly | 4120703968 | 2 |
| 22 | Bolt GB5782-M20*100flZnyc-12.9-480 | 4011010763 | 24 |
| 23 | Washer GB1230-20EpZn-45 | 4015000002 | 48 |
