LGMG Mine Truck Mine Truck – Oil – A0201-2702010221002
Category: Mine Truck > Mine Truck > M0860WAA0
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB97.1-16EpZn-300HV | 4015000181 | 6 |
| 2 | Nut GB6185.1-M16EpZn-10 | 4013010136 | 6 |
| 3 | Aluminium oil box cover | 4049010004 | 1 |
| 4 | Fuel sieve | 4110000046 | 1 |
| 5 | Bolt GB5782-M16*80EpZn-10.9 | 4011000438 | 2 |
| 6 | Bolt GB5782-M16*70EpZn-10.9 | 4011000824 | 4 |
| 7 | Fuel tank bracket assy | 4110000118 | 3 |
| 8 | Fixed plate | 27020101021 | 3 |
| 9 | Pin | 4110000120 | 3 |
| 10 | Pin GB91-3.2*22EpZn-Q235A | 4016000183 | 3 |
| 11 | Backing plate | 27020101971 | 2 |
