LGMG Mine Truck 2026 – Front leaf spring assy – G1200-4110706152
Category: 2026 > Mine Truck > MT106 > M1060W3E0M044
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | 12th leaf of front leaf spring | 4110706152012 | 1 |
| 2 | 13th leaf of front leaf spring | 4110706152013 | 1 |
| 3 | Center nut M16*1.5 | 4110000730014 | 1 |
| 4 | Center bolt M16*1.5*275 | 4110706152014 | 1 |
| 5 | Clip bolt | 4110702221016 | 2 |
| 6 | Rivet | 4110702278020 | 2 |
| 7 | Clip | 4110702221018 | 2 |
| 8 | Clip nut | 4110702221017 | 2 |
| 9 | Front leaf spring backing plate 320*90*3 | 4110706152015 | 1 |
| 10 | Leaf of FR leaf spring | 4110002083001 | 3 |
| 11 | 4th leaf of front leaf spring | 4110000730004 | 1 |
| 12 | 5th leaf of front leaf spring | 4110706152005 | 1 |
| 13 | 6th leaf of front leaf spring | 4110706152006 | 1 |
| 14 | 7th leaf of front leaf spring | 4110706152007 | 1 |
| 15 | 8th leaf of front leaf spring | 4110706152008 | 1 |
| 16 | 9th leaf of front leaf spring | 4110706152009 | 1 |
| 17 | 10th leaf of front leaf spring | 4110706152010 | 1 |
| 18 | 11th leaf of front leaf spring | 4110706152011 | 1 |
