LGMG MT50 Mine Truck – LH front leaf spring assy – G1200-4110000809
Category: Mine Truck > MT50 > M0500WE12
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Support plate | 4110000809010 | 1 |
| 2 | Center bolt | 4110000809011 | 1 |
| 3 | Center nut | 4110000809012 | 1 |
| 4 | Clip bolt | 4110000809013 | 4 |
| 5 | Clip | 4110000809014 | 2 |
| 6 | Rivet | 4110000809015 | 4 |
| 7 | Self-locking nut | 4110000809016 | 4 |
| 8 | Clip sleeve | 4110000809017 | 4 |
| 9 | Clamp | 4110000809018 | 2 |
| 10 | 1st leaf of front leaf spring | 4110000809001 | 1 |
| 11 | 2nd leaf of front leaf spring | 4110000809002 | 1 |
| 12 | 3rd leaf of front leaf spring | 4110000809003 | 1 |
| 13 | 4th leaf of front leaf spring | 4110000809004 | 1 |
| 14 | 5th leaf of front leaf spring | 4110000809005 | 1 |
| 15 | 6th leaf of front leaf spring | 4110000809006 | 1 |
| 16 | 7th leaf of front leaf spring | 4110000809007 | 1 |
| 17 | 8th leaf of front leaf spring | 4110000809008 | 1 |
| 18 | 9th leaf of front leaf spring | 4110000809009 | 1 |
