LGMG MT50 Mine Truck – Parking brake assy – J1100-2711010347
Category: Mine Truck > MT50 > M0500WE83
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Air reservoir bracket | 27110101221 | 1 |
| 2 | Bolt GB5783-M8*30EpZn-8.8 | 4011000107 | 4 |
| 3 | Thin nut M16*1.5 | 4120000234 | 1 |
| 4 | PLATE | 27110101601 | 1 |
| 5 | Joint M22-M16 | 27110101561 | 1 |
| 6 | Dual way check valve | 4120000361 | 1 |
| 7 | Joint M22-M12 | 27100104611 | 2 |
| 8 | Washer JB982-10 | 4015000140 | 2 |
| 9 | M10-M12 Joint | 27100102051 | 1 |
| 10 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 6 |
| 11 | Nut seat NG12 | 4120000190 | 8 |
| 12 | Air reservoir support 30L | 4120000718 | 1 |
| 13 | Nut GB6170-M10EpZn-8 | 4013000007 | 4 |
| 14 | Air reservoir 20L | 4120000360 | 1 |
| 15 | Hose clamp φ246-φ250 | 4120000177 | 2 |
| 16 | Washer JB982-22 | 4015000092 | 4 |
| 17 | Block | 27110101931 | 2 |
| 18 | Bolt GB5782-M8*50EpZn-8.8 | 4011000223 | 2 |
| 19 | Triple solenoid valve | 4120000484 | 1 |
| 20 | Nut seat NG6 | 4120000213 | 7 |
| 21 | Elastic element NG6 | 4120000211 | 7 |
| 22 | Elastic element NG12 | 4120000193 | 8 |
| 23 | Clip spring NG6 | 4120000212 | 7 |
| 24 | Nut seat NG8 | 4120000194 | 5 |
| 25 | Elastic element NG8 | 4120000197 | 5 |
| 26 | Clip spring NG8 | 4120000196 | 5 |
| 27 | Washer GB97.1-10EpZn-300HV | 4015000162 | 8 |
| 28 | Pressure switch block | 27110101381 | 1 |
| 29 | Reducing joint | 27110101891 | 1 |
| 30 | Button valve | 4120001046 | 1 |
| 31 | Washer GB97.1-6EpZn-300HV | 4015000207 | 2 |
| 32 | Bolt GB5783-M6*20EpZn-8.8 | 4011000101 | 2 |
| 33 | Clip spring NG12 | 4120000192 | 8 |
| 34 | connector | 27110101371 | 1 |
| 35 | Fagging | 27140108681 | 2 |
| 36 | Nut GB6170-M8EpZn-8 | 4013000033 | 10 |
| 37 | Washer GB97.1-8EpZn-300HV | 4015000072 | 10 |
| 38 | Plate | 27100106031 | 1 |
| 39 | Relay valve | 4120000137 | 1 |
| 40 | Bolt GB5783-M10*45EpZn-8.8 | 4011000514 | 2 |
| 41 | Hand brake valve | 4120000134 | 1 |
| 42 | T-connector M14-M12-M14 | 27110101341 | 1 |
| 43 | Joint M12-M12 | 27110101331 | 3 |
| 44 | Washer JB982-12 | 4015000327 | 3 |
| 45 | Plug NG12-M22*1.5 | 4120000201 | 1 |
| 46 | Air reservoir 30L（275） | 4120000142 | 1 |
| 47 | Hose clamp φ275-φ280 | 4120000178 | 2 |
| 48 | Drain valve | 4120000200 | 2 |
