LGMG MT50 Mine Truck – Plate – A0300-2703010480
Category: Mine Truck > MT50 > M0500HE40
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Water supply tube of water tank | 27030102031 | 1 |
| 2 | Bolt GB5783-M8*25EpZn-8.8 | 4011000106 | 4 |
| 3 | Washer GB97.1-8EpZn-300HV | 4015000072 | 4 |
| 4 | EXPANSION TANK BRACKET | 27030104621 | 1 |
| 5 | Washer GB96.1-12EpZn-300HV | 4015000186 | 2 |
| 6 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 2 |
| 7 | Bolt GB5783-M12*30EpZn-8.8 | 4011000089 | 2 |
| 8 | Expansion water tank | 4110000439 | 1 |
| 9 | Air pipe | 27030102021 | 2 |
| 10 | No longer used | 4190000343 | 4 |
| 11 | Plate | 27030104851 | 1 |
| 12 | Nut GB6185.1-M8EpZn-8 | 4013010118 | 1 |
| 13 | washer | 27030102011 | 2 |
| 14 | Rubber shock block | 4110000211 | 1 |
| 15 | Nut GB6170-M6EpZn-8 | 4013000028 | 3 |
| 16 | Bracket 1 | 27100103561 | 3 |
| 17 | Washer GB93-6-65Mn | 4015000035 | 3 |
| 18 | Washer GB97.1-6EpZn-300HV | 4015000207 | 3 |
| 19 | Hose clamp JB8870-D32 | 4017000011 | 2 |
| 20 | Engine pipe | 27030105101 | 1 |
| 21 | Engine water pipe | 27030105161 | 1 |
| 22 | Plate | 27030104841 | 1 |
| 23 | No longer used | 4019010001 | 4 |
| 24 | Radiator assy | 4190001539 | 1 |
| 25 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 8 |
| 26 | T-bolt clamp φ60-φ68 | 4190001613 | 6 |
| 27 | Plate | 27030104861 | 1 |
| 28 | Pipe | 27030104931 | 1 |
| 29 | Bracket 1 | 27100103561 | 1 |
