LGMG MT76 Mine Truck – Hub reductor – E12-2907001931
Category: Mine Truck > MT76 > M0760WE70
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 8 |
| 2 | O-ring LGB308-250*3.5-E | 4043000643 | 1 |
| 3 | Wheel trim cover | 29070017272 | 1 |
| 4 | Sun gear | 29070017181 | 1 |
| 5 | Adjusting shim | 29070011701 | 1 |
| 6 | Adjusting shim | 29070011711 | 1 |
| 7 | Sun gear shim | 29070012442 | 1 |
| 8 | Retaining ring GB894.1-52-65Mn | 4015000022 | 1 |
| 9 | Planet wheel shim | 29070017221 | 8 |
| 10 | Locating ring | 29070017231 | 8 |
| 11 | Wheel hub | 29070017122 | 1 |
| 12 | Roller pin GB309-P553-GCr15 | 4090000283 | 128 |
| 13 | Steel ball GB308-9.525-GCR15 | 4090000008 | 4 |
| 14 | Shaft-planetary | 29070017281 | 4 |
| 15 | Gear Planetary | 29070017191 | 4 |
| 16 | Inner ring gear assembly | 29070017351 | 1 |
| 17 | Round nut | 29070015591 | 1 |
| 18 | Screw GB70.1-M8*16EpZn-8.8 | 4014000033 | 2 |
| 19 | Bearing GB297-32224 | 4021000038 | 1 |
| 20 | Screw GB70.1-M12*40EpZn-8.8 | 4014000136 | 3 |
| 21 | Bearing GB297-32226 | 4021000287 | 1 |
| 22 | Wheel rim bolt | 29070017312 | 12 |
| 23 | Sealing ring GB13871.1-F17024015-F | 4030000994 | 1 |
| 24 | Sealing ring GB13871.1-FB17024015-D | 4030000995 | 1 |
| 25 | Dust cover | 29070013501 | 1 |
| 26 | Spacer sleeve | 29070018081 | 1 |
| 27 | O-ring GB3452.1-160*3.55G | 4030000452 | 1 |
| 28 | O-ring LGB308-340*3.5-E | 4043000644 | 1 |
| 29 | Planetary gear carrier | 29070017132 | 1 |
| 30 | Oil drain plug | 29050013351 | 1 |
| 31 | O-ring LGB168-12331 | 4041000779 | 1 |
| 32 | Shim | 29070017291 | 1 |
| 33 | Magnetic plug | 29070011751 | 1 |
| 34 | O-ring GB3452.1-13.2*1.80G | 4030000076 | 1 |
