LGMG MT76 Mine Truck – System – K3-2720010403
Category: Mine Truck > MT76 > MT76
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 4 |
| 2 | Washer GB861.1-10EpZn-65Mn | 4015000195 | 3 |
| 3 | Nut GB6170-M10EpZn-8 | 4013000007 | 4 |
| 4 | Wire | 27200103991 | 1 |
| 5 | Pipe clamp | 26370001941 | 1 |
| 6 | FAGGING | 27140101401 | 2 |
| 7 | Bolt GB5783-M8*25EpZn-8.8 | 4011000106 | 2 |
| 8 | Rear work lamp | 4130000263 | 4 |
| 9 | Right lamp guard | 27200102321 | 1 |
| 10 | Left lamp guard | 27200102311 | 1 |
| 11 | WIRE | 27200100021 | 1 |
| 12 | Cable protector | 27140108701 | 1 |
| 13 | Parking pressure switch 0.55MPa | 4130000006 | 1 |
| 14 | Electromagnetic valve air pressure switch 0.3MPa | 4130000007 | 1 |
| 15 | BACK ALARMING | 4130000351 | 1 |
| 16 | Washer GB96.1-6EpZn-300HV | 4015000198 | 8 |
| 17 | Bolt GB5783-M6*20EpZn-8.8 | 4011000101 | 8 |
| 18 | Washer GB93-6-65Mn | 4015000035 | 8 |
| 19 | LAMPSHADE | 27200101651 | 2 |
| 20 | Support | 27200102962 | 2 |
| 21 | LED INDICATOR LAMP | 4130000266 | 1 |
| 22 | Battery 6-QW-120B | 4130000059 | 2 |
| 23 | LED INDICATOR LAMP | 4130000265 | 1 |
| 24 | POSITION LIMITE SWITCH XJK-001 | 4130000365 | 1 |
| 25 | fagging | 27140108691 | 1 |
| 26 | Air pressure sensor YG2221S（M16*1.5） | 4130000012 | 1 |
| 27 | Starting motoer wire P50*3900 | 27200104021 | 1 |
| 28 | WIRE P50*400 | 27200100041 | 1 |
| 29 | Power switch 37030020010 | 4130000307 | 1 |
| 30 | Bolt GB5783-M8*35EpZn-8.8 | 4011000195 | 14 |
| 31 | Washer GB97.1-8EpZn-300HV | 4015000072 | 14 |
| 32 | Nut GB6170-M8EpZn-8 | 4013000033 | 14 |
| 33 | Engine ground wire P50*700 | 27200101931 | 1 |
