LGMG MT80 Mine Truck – Front suspension – G2-2712010897
Category: Mine Truck > MT80 > 0M0800WA0P
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | No longer used | 4013010182 | 2 |
| 2 | Bolt GB5782-M10*40EpZn-8.8 | 4011000504 | 2 |
| 3 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 2 |
| 4 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 5 | Front suspension rear limit block bracket (left) | 27120108931 | 1 |
| 6 | Front suspension rear limit block bracket (right) | 27120108951 | 1 |
| 7 | Hollow rubber buffer block | 4190000636 | 2 |
| 8 | BOLT | 4011010260 | 6 |
| 9 | Nut GB6185.2-M12EpZn-8 | 4013010159 | 8 |
| 10 | Front spring bracket | 27120103661 | 2 |
| 11 | before steel plate springs | 27120103511 | 2 |
| 12 | BOLT GB5786-M18*1.5*65EpZn-10.9 | 4011000792 | 20 |
| 13 | Nut GB6185.2-M18*1.5EpZn-10 | 4013010158 | 20 |
| 14 | Bush | 27120103521 | 4 |
| 15 | Spring pin | 27120107022 | 6 |
| 16 | Washer | 27120107031 | 6 |
| 17 | Bolt GB5783-M10*20EpZn-10.9 | 4011000759 | 6 |
| 18 | Washer GB93-10-65Mn | 4015000025 | 6 |
| 19 | Grease nipple JB7940.1-M10*1 | 4030000065 | 6 |
| 20 | No longer used | 4030000107 | 6 |
| 21 | Washer | 27120103551 | 12 |
| 22 | Front spring U-bolt | 27120108921 | 4 |
| 23 | Backing plate | 27120104201 | 4 |
| 24 | Shock absorber bracket | 27120108811 | 2 |
| 25 | Bolt GB5786-M12*1.25*40EpZn-8.8 | 4011010169 | 8 |
| 26 | FR suspension stop block | 4110000018 | 2 |
| 27 | Shock absorber | 27120104171 | 2 |
| 28 | Bolt GB5785-M16*1.5*90EpZn-10.9 | 4011000879 | 2 |
| 29 | Stop bracket | 27120108781 | 2 |
| 30 | Bolt GB5783-M16*55EpZn-8.8 | 4011000612 | 16 |
| 31 | Nut GB6185.1-M16EpZn-8 | 4013010122 | 16 |
| 32 | plate | 4190000678 | 2 |
| 33 | Self-locking nut with the shoulder | 27120103611 | 8 |
| 34 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 6 |
| 35 | Washer GB97.1-12EpZn-300HV | 4015000168 | 6 |
| 36 | Bolt GB5783-M12*35EpZn-8.8 | 4011000090 | 4 |
| 37 | Front spring bracket | 27120103711 | 2 |
| 38 | diaoer | 27120107631 | 2 |
| 39 | Two beam assembly | 27120104111 | 1 |
| 40 | Bolt GB5782-M16*65EpZn-10.9 | 4011010012 | 16 |
| 41 | Nut GB6185.1-M16EpZn-10 | 4013010136 | 16 |
| 42 | Washer GB1230-16-45 | 4015010101 | 16 |
| 43 | Washer 18 | 27120105411 | 20 |
| 44 | Bolt GB5785-M16*1.5*70EpZn-8.8 | 4011000499 | 4 |
| 45 | Nut GB6185.2-M12*1.25EpZn-10 | 4013010189 | 6 |
| 46 | Nut GB6185.2-M16*1.5EpZn-8 | 4013010168 | 2 |
| 47 | Washer GB97.1-16EpZn-300HV | 4015000181 | 20 |
| 48 | Shock absorber down bracket assembly | 27120104041 | 2 |
| 49 | Front spring clamp | 27120103591 | 2 |
| 50 | BOLT | 4011010168 | 2 |
| 51 | Washer GB848-16EpZn-300HV | 4015010212 | 2 |
