LGMG MT80C Mine Truck – STEERING ASSEMBLY – H1-2715010525
Category: Mine Truck > MT80C > MT80C
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Steel pipe | 27150103991 | 1 |
| 2 | Straight joint LGB155-01822 | 4041000822 | 5 |
| 3 | O-ring GB3452.1-19.0*2.65G | 4030000280 | 6 |
| 4 | Combination joint LGB143-02213 | 4041001156 | 5 |
| 5 | O-Ring GB3452.1-12.5*1.80G | 4030000242 | 5 |
| 6 | Straight joint | 27150102981 | 1 |
| 7 | Combination joint LGB143-02616 | 4041001006 | 1 |
| 8 | O-ring GB3452.1-15.0*1.80G | 4030000501 | 1 |
| 9 | Steel pipe | 27150103821 | 1 |
| 10 | PIPE | 27150103841 | 1 |
| 11 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 2 |
| 12 | PIPE | 27150103861 | 1 |
| 13 | arm | 4120000372 | 1 |
| 14 | BRACKET | 27150103921 | 1 |
| 15 | Baseplate LGB160-2028 | 4041001240 | 1 |
| 16 | U-bolt LGB159-12028 | 4041001239 | 1 |
| 17 | HOSE LGB165-410300 | 4041010053 | 1 |
| 18 | WASHER LGB303-30*60*1 | 4043010003 | 2 |
| 19 | WASHER LGB303-30*60*2 | 4043010004 | 2 |
| 20 | T-CLAMPΦ40 | 4019010158 | 2 |
| 21 | hose | 27150103671 | 1 |
| 22 | Nut GB6170-M10EpZn-8 | 4013000007 | 2 |
| 23 | Washer JB982-33 | 4015000143 | 1 |
| 24 | CONNECTOR | 27150103941 | 1 |
| 25 | HOSE LGB127-406137 | 4041010056 | 1 |
| 26 | CYLINDER HSGL-70*35*415-785 | 4120000328 | 1 |
| 27 | Bolt GB5783-M12*30EpZn-8.8 | 4011000089 | 1 |
| 28 | Nut GB6170-M12EpZn-8 | 4013000011 | 2 |
| 29 | Washer GB97.1-12EpZn-300HV | 4015000168 | 4 |
| 30 | Pipe clamp, for fixing control valve harness | 26370001961 | 2 |
| 31 | HOSE LGB128-406090 | 4041010055 | 1 |
| 32 | plate | 27150100401 | 2 |
| 33 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 34 | Bolt GB5783-M6*16EpZn-8.8 | 4011000289 | 4 |
| 35 | Washer GB93-6EpZn-65Mn | 4015000213 | 4 |
| 36 | Washer GB97.1-6EpZn-300HV | 4015000207 | 4 |
| 37 | Bolt GB5783-M12*40EpZn-8.8 | 4011000091 | 1 |
| 38 | pin | 27150100381 | 2 |
| 39 | Grease nipple JB7940.1-M10*1 | 4030000065 | 2 |
| 40 | Front axle steering holder | 27060100061 | 1 |
| 41 | Bolt GB5783-M16*45EpZn-10.9 | 4011000564 | 6 |
| 42 | Washer GB93-16-65Mn | 4015000098 | 6 |
| 43 | BRACKET | 27150103931 | 1 |
| 44 | BRACKET | 27150102691 | 1 |
| 45 | O-ring GB3452.1-28.0*2.65G | 4030000090 | 1 |
| 46 | joint | 27150103651 | 1 |
| 47 | Hose LGB128-406060 | 4041000826 | 1 |
| 48 | PIPE | 27150103881 | 1 |
| 49 | PIPE | 27150103901 | 1 |
| 50 | Bolt GB5786-M16*1.5*45EpZn-8.8 | 4011000494 | 1 |
| 51 | BLOCK | 27150102811 | 2 |
| 52 | Steering link headball | 27150100671 | 1 |
| 53 | Redirector bracket | 27150102661 | 1 |
| 54 | No longer used | 4011010178 | 5 |
| 55 | U-Bolt LGB159-11826 | 4041001225 | 3 |
| 56 | STEERING VALVE NT12590M | 4120000331 | 1 |
| 57 | Steering link | 27150103551 | 1 |
| 58 | Bolt GB5782-M12*60EpZn-8.8 | 4011000260 | 2 |
| 59 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 2 |
| 60 | Steering link headball | 27150100661 | 1 |
| 61 | Baseplate LGB160-1826 | 4041001226 | 3 |
| 62 | Nut GB6170-M8EpZn-8 | 4013000033 | 8 |
| 63 | Washer GB97.1-8EpZn-300HV | 4015000072 | 8 |
| 64 | GEAR PUMP | 4120000124 | 1 |
