LGMG MT95D Mine Truck – Service brake assembly – J1000-2710010790002
Category: Mine Truck > MT95D > M095DWA00
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | CONNECTOR | 27100100661 | 4 |
| 2 | Washer GB97.1-10EpZn-300HV | 4015000162 | 6 |
| 3 | Nut GB6170-M8EpZn-8 | 4013000033 | 2 |
| 4 | Washer GB97.1-8EpZn-300HV | 4015000072 | 2 |
| 5 | Plate | 27100106811 | 1 |
| 6 | Relay valve | 4120001087 | 1 |
| 7 | Nut GB6170-M10EpZn-8 | 4013000007 | 6 |
| 8 | Bolt GB5782-M10*50EpZn-8.8 | 4011000048 | 4 |
| 9 | Pipe bracket | 27100107392 | 1 |
| 10 | Hose clamp φ246-φ250 | 4120000177 | 2 |
| 11 | Washer JB982-16 | 4015000141 | 6 |
| 12 | Air reservoir 30L（246） | 4120000143 | 1 |
| 13 | Clip spring NG12 | 4120000192 | 11 |
| 14 | Elastic element NG12 | 4120000193 | 11 |
| 15 | Nut seat NG12 | 4120000190 | 11 |
| 16 | Bracket of 30L reservior(246) | 27100106321 | 1 |
| 17 | Joint m12-m12 | 27100104301 | 2 |
| 18 | Washer JB982-12 | 4015000327 | 2 |
| 19 | Fagging | 27100107131 | 1 |
| 20 | Bracket 1 | 27100103561 | 2 |
| 21 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 4 |
| 22 | M16-M18 rectangular connector | 27100100641 | 2 |
| 23 | T-connector m14-npt1/8-m14 | 27100106991 | 1 |
| 24 | String casing | 27140105021 | 1 |
| 25 | Fagging | 27140119481 | 1 |
| 26 | Braking pipe assembly | 4120001551 | 1 |
| 27 | Sleeve | 27100107421 | 2 |
| 28 | Pipe bracket | 27100107402 | 1 |
| 29 | Bolt GB5782-M10*85EpZn-8.8 | 4011010016 | 2 |
| 30 | Air pipe gpu-13-i-880-sg | 27100107441 | 2 |
| 31 | Partition connector body L12 NG12 | 4120000257 | 2 |
| 32 | Nut M18 | 4120000230 | 5 |
