LGMG MT95H Mine Truck – Exhaust and heating system assembly – A2400-2724010317
Category: Mine Truck > MT95H > M095HHA10
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Pipe | 4190003587 | 1 |
| 2 | Exhaust brake butterfly valve | 4110000157 | 1 |
| 3 | Bolt GB5782-M10*65EpZn-8.8 | 4011000497 | 2 |
| 4 | Washer GB97.1-10EpZn-300HV | 4015000162 | 6 |
| 5 | Muffler | 4190003589 | 1 |
| 6 | Bolt GB5783-M12*45EpZn-8.8 | 4011000207 | 4 |
| 7 | Plate | 27010110671 | 1 |
| 8 | Upr exhaust pipe | 4190003585 | 1 |
| 9 | Tube | 27240103161 | 1 |
| 10 | Protecting cover | 27240101581 | 1 |
| 11 | Bolt GB5783-M12*40EpZn-8.8 | 4011000091 | 4 |
| 12 | No longer used | 4019010204 | 2 |
| 13 | Support | 27240103151 | 1 |
| 14 | Bolt GB16674.1-M10*120EpZn-8.8 | 4011000601 | 4 |
| 15 | Bolt GB5783-M6*25EpZn-8.8 | 4011000276 | 18 |
| 16 | Protecting cover | 27240103141 | 2 |
| 17 | Washer GB96.1-6EpZn-300HV | 4015000198 | 18 |
| 18 | Plate | 27010110711 | 3 |
| 19 | Plate | 27010110661 | 1 |
| 20 | TENSIONING LEVER | 27010101611 | 3 |
| 21 | Nut GB6170-M8EpZn-8 | 4013000033 | 12 |
| 22 | Washer GB96.1-12EpZn-300HV | 4015000186 | 8 |
| 23 | Washer GB96.1-8EpZn-300HV | 4015000256 | 6 |
| 24 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 4 |
| 25 | Exhaust conversion box | 4190003584 | 1 |
| 26 | Clamp | 4110000768 | 4 |
| 27 | Bolt GB5782-M10*75EpZn-8.8 | 4011000052 | 4 |
| 28 | Nut GB6170-M10EpZn-8 | 4013000007 | 22 |
| 29 | Exhaust pipe strap | 27240102331 | 1 |
| 30 | Lower exhaust pipe | 4190003586 | 1 |
