LGMG MT95H Mine Truck – Radiator assembly – A0300-2703011505
Category: Mine Truck > MT95H > M095HHAB1
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | No longer used | 4019010204 | 8 |
| 2 | FRONT AXLE ASSEMBLY | 27030112701 | 1 |
| 3 | PLATE | 27030115031 | 1 |
| 4 | Wind guide cover | 4110002119 | 1 |
| 5 | Radiator assy | 4110702339 | 1 |
| 6 | Support | 27030109692 | 2 |
| 7 | Bolt GB5783-M10*45EpZn-8.8 | 4011000514 | 4 |
| 8 | Nut GB6170-M10EpZn-8 | 4013000007 | 4 |
| 9 | Washer GB96.1-10EpZn-300HV | 4015000197 | 8 |
| 10 | No longer used | 4019010200 | 4 |
| 11 | Wind deflector | 27030112081 | 1 |
| 12 | Water outlet pipe | 27030112711 | 1 |
| 13 | Pipe1 | 27030111451 | 1 |
| 14 | Plate | 27030111741 | 4 |
| 15 | Radiator shock absorber assy | 4110001445 | 2 |
| 16 | Plate | 27030109021 | 2 |
| 17 | Nut GB6171-M14*1.5EpZn-8 | 4013000119 | 4 |
| 18 | Bolt GB5783-M10*90EpZn-8.8 | 4011000956 | 4 |
| 19 | Radiator bar | 4110001451 | 2 |
| 20 | Nut GB6170-M12EpZn-8 | 4013000011 | 6 |
| 21 | Bolt GB5782-M14*85EpZn-8.8 | 4011010630 | 2 |
| 22 | PLATE | 27030115061 | 1 |
| 23 | Nut GB6185.1-M14EpZn-8 | 4013010121 | 2 |
| 24 | Plate | 27030109731 | 2 |
| 25 | Nut GB6185.1-M8EpZn-8 | 4013010118 | 6 |
| 26 | Washer GB97.1-8EpZn-300HV | 4015000072 | 6 |
| 27 | Bolt GB5783-M8*25EpZn-8.8 | 4011000106 | 4 |
| 28 | Plate | 27030115001 | 2 |
| 29 | Bolt GB5782-M8*55EpZn-8.8 | 4011000415 | 2 |
| 30 | Support i | 27030105861 | 2 |
| 31 | Pipe | 27030114961 | 1 |
