LGMG MT95H Mine Truck – Reserve – A1800-2718010415
Category: Mine Truck > MT95H > M095HWA95
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Reducing joint | 27110101891 | 1 |
| 2 | Air inlet pipe | 27180103721 | 1 |
| 3 | No longer used | 4019000076 | 1 |
| 4 | Hose clamp JB8870-D32 | 4017000011 | 2 |
| 5 | Pipe | 27180102192 | 1 |
| 6 | Wire | 27200107621 | 1 |
| 7 | Vacuum level alarm | 4110001427 | 1 |
| 8 | Bolt GB5782-M12*80EpZn-8.8 | 4011000334 | 4 |
| 9 | Washer GB97.1-12EpZn-300HV | 4015000168 | 8 |
| 10 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 4 |
| 11 | T-Hoop φ148-φ156 | 4190002629 | 1 |
| 12 | Elastic element NG8 | 4120000197 | 1 |
| 13 | Clip spring NG8 | 4120000196 | 1 |
| 14 | Nut seat NG8 | 4120000194 | 1 |
| 15 | Pipe | 27110103241 | 1 |
