LGMG MTE106H 2025 – Gear pump assy – M1601-2716014176.S1D
Category: 2025 > MTE106H > C106HE0A0A501
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Nut GB6185.1-M12flZnyc-10-480 | 4013010379 | 4 |
| 2 | Nut GB6185.1-M8EpZn-8 | 4013010118 | 1 |
| 3 | Washer GB97.1-12flZnyc-300HV-480 | 4015010340 | 4 |
| 4 | Gear pump HGPS3Q120Q3A2RJ2 | 4120714205 | 1 |
| 5 | Pump coupling | 4120001055 | 1 |
| 6 | Joint 1CB-36-24WD | 4120715079 | 1 |
| 7 | Joint 1CB-52-32WD | 4120715080 | 1 |
| 8 | Welded joint m52-φ56 | 27160141662 | 1 |
| 9 | Oil suction hose 55*6 | 27160141741 | 1 |
| 10 | Gear pump bracket wldmt | 27160141141 | 1 |
| 11 | Bolt GB5783-M8*65EpZn-8.8 | 4011010633 | 1 |
| 12 | Bolt GB5783-M12*50flZnyc-10.9-480 | 4011010861 | 4 |
