LGMG MTE86H 2025 – Gear pump installation – M1601-2716014180.S1A
Category: 2025 > MTE86H > C0862E0A0A001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bracket wldmt | 27160141081 | 1 |
| 2 | Bolt GB5783-M12*45EpZn-10.9 | 4011000758 | 4 |
| 3 | Washer GB97.1-12EpZn-300HV | 4015000168 | 4 |
| 4 | Nut GB6185.1-M12EpZn-10 | 4013010134 | 4 |
| 5 | Gear pump HGPS3Q120Q3A2RJ2 | 4120714205 | 1 |
| 6 | Joint 1CB-36-24WD | 4120715079 | 1 |
| 7 | Pipe wldmt | 27160141061 | 1 |
| 8 | Joint 1CB-52-32WD | 4120715080 | 1 |
| 9 | Welded joint m52-φ56 | 27160141662 | 1 |
| 10 | Oil suction hose 55*6 | 27160141781 | 1 |
| 11 | Bolt GB5783-M8*65EpZn-8.8 | 4011010633 | 1 |
| 12 | Nut GB6185.1-M8EpZn-8 | 4013010118 | 1 |
| 13 | Pump coupling | 4120001055 | 1 |
