LGMG MTH116 2025 – Body safety prop assy – I4001-2740012356.S1A
Category: 2025 > MTH116 > C1160Y3A0A002
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt qc340-m18*1.5*70flznyc-12.9-480 | 4011011843 | 3 |
| 2 | Pin GB91-6.3*50EpZn-Q235A | 4016000040 | 1 |
| 3 | Plate | 27170263411 | 1 |
| 4 | Fastening bolt damping block | 27170140901 | 2 |
| 5 | Board | 27400109001 | 1 |
| 6 | Bolt QC340-M18*1.5*50flZnyc-12.9 | 4011011708 | 2 |
| 7 | Nut GB6177.2-RLM18*1.5flZnyc-12 | 4013010562 | 6 |
| 8 | Safety prop pin 32*170 | 27400123601 | 1 |
| 9 | WASHER GB97.1-34EpZn-300HV | 4015010301 | 1 |
| 10 | Safety prop mount wldmt | 27400123581 | 1 |
| 11 | Bolt QC340-M18*1.5*60flZnyc-12.9 | 4011011698 | 1 |
