LGMG MTH116 2025 – Centralized lubrication system – K2501-2725010345.S1A
Category: 2025 > MTH116 > C1160Y3A0A002
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB16674.1-M10*30flZnyc-8.8-480 | 4011010712 | 11 |
| 2 | Plate | 27150114642 | 2 |
| 3 | Bolt GB16674.1-M10*25flZnyc-8.8-480 | 4011011015 | 5 |
| 4 | Bolt GB16674.1-M6*50flZnyc-8.8-480 | 4011010873 | 4 |
| 5 | Nut GB6177.1-M6flZnyc-8-480 | 4013010388 | 4 |
| 6 | Bracket 01 | 27250103471 | 1 |
| 7 | Bolt GB16674.1-M8*25flZnyc-8.8-480 | 4011010994 | 2 |
| 8 | Washer GB96.1-8flZnyc-300HV-480 | 4015010289 | 1 |
| 9 | Centralised lubrication assembly | 27250100371 | 1 |
| 10 | Bolt GB16674.1-M8*20flZnyc-8.8-480 | 4011010966 | 23 |
| 11 | Centralized lubrication sys lg25-jzrh-12 | 4120716782 | 1 |
| 12 | Bracket 220*180*6 | 27250102851 | 1 |
| 13 | Bolt gb16674.1-m10*45flznyc-8.8-480 | 4011011465 | 2 |
| 14 | GROMMET | 4043010319 | 1 |
| 15 | Bracket 280*270*140 | 27250103461 | 1 |
| 16 | Bolt GB16674.1-M10*40flZnyc-8.8-480 | 4011011086 | 3 |
| 17 | Nut gb6187.1-m10flznyc-8-480 | 4013010628 | 17 |
| 18 | Bolt gb5789-m14*120flznyc-12.9-480 | 4011011932 | 3 |
| 19 | Nut gb6187.1-m14flznyc-12-480 | 4013010632 | 3 |
| 20 | Cable tie 14400342 | 4130703098 | 32 |
| 21 | Bracket 45 | 27030139931 | 5 |
