LGMG Off-Highway Dump Truck 2020 – Cooler assembly – A0300-2703011827
Category: 2020 > Off-Highway Dump Truck > MT95D > M095DWA93
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Cold air intake pipe | 27030105791 | 1 |
| 2 | No longer used | 4019010211 | 4 |
| 3 | Intercooler inlet air pipe | 27030108401 | 1 |
| 4 | Radiator assy | 4110001572 | 1 |
| 5 | Thermostat hose pipe 2 | 27030108361 | 1 |
| 6 | T-Clamp 78-86 | 4190002212 | 4 |
| 7 | Inlet pipe of engine | 27030108381 | 1 |
| 8 | Pipe | 27030110712 | 1 |
| 9 | Inlet pipe 1 of engine | 27030108371 | 1 |
| 10 | T-bolt | 4019010168 | 2 |
| 11 | Pipe | 27030115791 | 1 |
| 12 | Thermostat hose assembly | 27030112321 | 1 |
| 13 | External thermostat | 4110000623 | 1 |
| 14 | Pipe | 27030110721 | 1 |
| 15 | Pipe | 27030110792 | 1 |
| 16 | Pipeⅰ | 27030118351 | 1 |
| 17 | Pipeⅱ | 27030118361 | 1 |
| 18 | Expansion tank | 27030109281 | 1 |
| 19 | Pipe | 27030105992 | 1 |
| 20 | Cooler assemble support | 27030109981 | 1 |
| 21 | Glass fiber Reinforced plastic wind guide cover | 4110001522 | 1 |
| 22 | Pipe | 27030110831 | 1 |
| 23 | Pipe | 27030118371 | 1 |
| 24 | Pipe | 27030110781 | 1 |
| 25 | Support assemble | 27030118421 | 1 |
| 26 | Connection hose200 | 27030109181 | 4 |
| 27 | Pipe | 27030110731 | 1 |
| 28 | No longer used | 4019010101 | 18 |
| 29 | Pipe | 27030110902 | 1 |
