LGMG Off-Highway Dump Truck 2020 – Front leaf spring assy – G1200-4110702189
Category: 2020 > Off-Highway Dump Truck > MT60D > M060DWA31
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | 11th leaf of front leaf spring | 4110702189011 | 1 |
| 2 | 12th leaf of front leaf spring | 4110702189012 | 1 |
| 3 | 13th leaf of front leaf spring | 4110702189013 | 1 |
| 4 | Center bolt | 4110702189018 | 1 |
| 5 | Bolt | 4110702189017 | 4 |
| 6 | Bushing | 4110702189005 | 4 |
| 7 | Self-locking nut | 4110702189016 | 4 |
| 8 | Clamp | 4110702189004 | 2 |
| 9 | Rivet | 4110702189015 | 4 |
| 10 | Clamp | 4110702189014 | 2 |
| 11 | No longer used- | 4110702189019 | 1 |
| 12 | 1st leaf of front leaf spring | 4110702189001 | 1 |
| 13 | 2nd leaf of front leaf spring | 4110702189002 | 1 |
| 14 | Leaf of front leaf spring | 4110702189003 | 3 |
| 15 | 6th leaf of front leaf spring | 4110702189006 | 1 |
| 16 | 7th leaf of front leaf spring | 4110702189007 | 1 |
| 17 | 8th leaf of front leaf spring | 4110702189008 | 1 |
| 18 | 9th leaf of front leaf spring | 4110702189009 | 1 |
| 19 | 10th leaf of front leaf spring | 4110702189010 | 1 |
