LGMG Off-Highway Dump Truck 2020 – Tail signal module – K2000-2720011204
Category: 2020 > Off-Highway Dump Truck > CMT96 > C0960HA11-1
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Rubber insert | 27200107141 | 2 |
| 2 | Plate | 27200111281 | 1 |
| 3 | Bolt GB5783-M12*30EpZn-8.8 | 4011000089 | 4 |
| 4 | Washer GB96.1-12EpZn-300HV | 4015000186 | 4 |
| 5 | Nut GB6170-M12EpZn-8 | 4013000011 | 4 |
| 6 | Frame | 27200111271 | 1 |
| 7 | Cargo lifting switch XJK-010-09 | 4130000641 | 1 |
| 8 | Bolt GB16674.1-M12*25EpZn-8.8 | 4011000560 | 3 |
| 9 | Nut GB6187.1-M12EpZn-10 | 4013010322 | 3 |
| 10 | Washer GB97.1-12EpZn-300HV | 4015000168 | 3 |
| 11 | Reverse buzzer DDB101-LG | 4130000294 | 1 |
| 12 | Screw GB70.1-M4*12EpZn-8.8 | 4014010172 | 5 |
| 13 | Washer GB97.1-4EpZn-300HV | 4015000135 | 5 |
| 14 | Bolt GB5783-M8*35EpZn-8.8 | 4011000195 | 2 |
| 15 | Washer GB97.1-8EpZn-300HV | 4015000072 | 10 |
| 16 | Nut GB6170-M8EpZn-8 | 4013000033 | 8 |
| 17 | Angle sensor SYSA | 4130000734 | 2 |
| 18 | Tilt sensor support | 27200111911 | 2 |
| 19 | Guard | 27140105031 | 2 |
| 20 | Brake & turn signal lamp STTD-40 | 4130001149 | 2 |
| 21 | White lamp work lamp WK-005 | 4130001150 | 2 |
