LGMG Off-Highway Dump Truck 2021 – Cab assy – L1301-2713013020.S1C
Category: 2021 > Off-Highway Dump Truck > MT86H > M086HW3A0M004-1
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB97.1-30EpZn-300HV | 4015000119 | 2 |
| 2 | Bolt GB5785-M30*2*155EpZn-8.8 | 4011000397 | 2 |
| 3 | Bolt GB5783-M10*35EpZn-10.9 | 4011000569 | 16 |
| 4 | Washer GB97.1-10EpZn-300HV | 4015000162 | 16 |
| 5 | Shock absorber | 4190704147 | 4 |
| 6 | Screw GB818-M5*12EpZn-4.8 | 4014000048 | 2 |
| 7 | Washer GB97.1-5EpZn-300HV | 4015000110 | 2 |
| 8 | Nut GB6170-M8EpZn-8 | 4013000033 | 4 |
| 9 | Washer GB97.1-8EpZn-300HV | 4015000072 | 6 |
| 10 | Bolt GB5783-M8*20EpZn-8.8 | 4011000105 | 6 |
| 11 | Fixed LH cab | 4190706946 | 1 |
| 12 | Washer GB97.1-16EpZn-300HV | 4015000181 | 4 |
| 13 | Screw GB818-M6*12EpZn-4.8 | 4011000194 | 3 |
| 14 | Nut GB6185.1-M16EpZn-8 | 4013010122 | 4 |
| 15 | Side Down Mirror WS33002550058 | 4190703759 | 1 |
| 16 | Wide angle rearview mirror WS33002550050 | 4190703755 | 1 |
| 17 | Main rearview mirror WS33002550049 | 4190703754 | 1 |
| 18 | Fire extinguisher bracket | 4190003487 | 1 |
| 19 | Fire extinguisher | 4190003486 | 1 |
| 20 | Seat assy | 4190003462 | 1 |
| 21 | Spacer | 27130124861 | 2 |
| 22 | Spring | 27130116051 | 2 |
