LGMG Off-Highway Dump Truck 2022 – Air filter assy – A1801-2718010386
Category: 2022 > Off-Highway Dump Truck > MT60 > M0600WE95
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | No longer used | 4019010001 | 1 |
| 2 | Bolt GB5782-M12*75EpZn-8.8 | 4011000874 | 2 |
| 3 | Bolt GB16674.1-M10*25EpZn-12.9 | 4011010295 | 8 |
| 4 | Support assembly ⅱ | 27180103021 | 1 |
| 5 | Air filter intake air pipe | 27180103871 | 1 |
| 6 | Vacuum level alarm | 4110001427 | 1 |
| 7 | Wire | 27200107621 | 1 |
| 8 | T-bolt clamp φ188-φ196 | 4190002630 | 1 |
| 9 | PLATE | 27180104131 | 1 |
| 10 | PLATE | 27180104141 | 1 |
| 11 | High level intake assy | 4190002593 | 1 |
| 12 | Rubber mat | 27030107261 | 1 |
| 13 | Nut GB6170-M10EpZn-8 | 4013000007 | 4 |
| 14 | Washer GB96.1-10EpZn-300HV | 4015000197 | 2 |
| 15 | Bolt GB5782-M12*80EpZn-8.8 | 4011000334 | 2 |
| 16 | Air filter assy（Donaldson） | 4190002628 | 1 |
| 17 | Connecting hose | 4190002594 | 1 |
| 18 | Support assembly ⅰ | 27180102961 | 1 |
| 19 | Support | 27180105251 | 1 |
| 20 | Washer GB96.1-12EpZn-300HV | 4015000186 | 12 |
| 21 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 12 |
| 22 | Washer GB97.1-12EpZn-300HV | 4015000168 | 12 |
| 23 | Bolt GB5782-M12*110EpZn-8.8 | 4011000262 | 8 |
