LGMG Off-Highway Dump Truck 2022 – ASM-Air handling unit assy – J1001-2710011656
Category: 2022 > Off-Highway Dump Truck > RT106 > R1060W3A0A000
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Rubber clip | 27100108841 | 2 |
| 2 | The dryer bracket | 27100112661 | 1 |
| 3 | Bolt GB5786-M12*1.5*30EpZn-8.8 | 4011000317 | 3 |
| 4 | Air Handling unit | 4120001482 | 1 |
| 5 | Pipe assembly | 27100116491 | 1 |
| 6 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 2 |
| 7 | Bolt GB5782-M10*65EpZn-8.8 | 4011000497 | 2 |
| 8 | Washer GB96.1-10EpZn-300HV | 4015000197 | 2 |
| 9 | Plate | 27100112633 | 1 |
| 10 | Plate | 27100108872 | 1 |
