LGMG Off-Highway Dump Truck 2022 – Chassis electric system – K2002-2720011523
Category: 2022 > Off-Highway Dump Truck > MT86H- > M086HW3A0A012
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Frame wire | 27200110803 | 1 |
| 2 | Frame central electrical module | 27200107521 | 1 |
| 3 | Electrical module | 27200107641 | 1 |
| 4 | Battery wire p70*3900 | 27200106551 | 1 |
| 5 | Red battery cable sheath | 26370002451 | 1 |
| 6 | Wire p70*550 | 27200111461 | 1 |
| 7 | Electrical module | 27200107261 | 1 |
| 8 | Signal module | 27200115241 | 1 |
