LGMG Off-Highway Dump Truck 2022 – Drive shaft assy – F0900-4110705674
Category: 2022 > Off-Highway Dump Truck > RT126 > R1260W3A0M001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Connecting fork 3570-225062-Q | 4110705663001 | 1 |
| 2 | Snap ring 19036311063 | 4110705471002 | 1 |
| 3 | Cardan assy 3570-2205080-T | 4110001049004 | 1 |
| 4 | Spline shaft fork 3570-2205016-KL376 | 4110705674001 | 1 |
| 5 | No longer used | 4090100154 | 1 |
| 6 | Sheath seal assy 19036311020-1L170S | 4110705049002 | 1 |
| 7 | Spline hub 3570-2205097-D | 4110705049003 | 1 |
| 8 | Shaft tube φ120*5 | 4110001384005 | 1 |
| 9 | Cardan fork 3570-2205096-C | 4110705663003 | 1 |
