LGMG Off-Highway Dump Truck 2022 – Engine electric system – K3400-2734010615-G1
Category: 2022 > Off-Highway Dump Truck > RT136 > R1260W3A0M002
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Power cable cap（Red） | 25320015671 | 3 |
| 2 | Wire | 27340106461 | 1 |
| 3 | Wire | 27340106451 | 1 |
| 4 | Battery wire p70*5000 | 27200106061 | 1 |
| 5 | L-support-60 | 27620000711 | 17 |
| 6 | Cable tie HS-J117 | 4130704969 | 15 |
| 7 | Wire | 27340108941 | 1 |
| 8 | Cable tie 14400342 | 4130703098 | 25 |
| 9 | Bolt GB5783-M8*16EpZn-8.8 | 4011000102 | 1 |
| 10 | Washer GB97.1-8EpZn-300HV | 4015000072 | 1 |
| 11 | Bolt GB5783-M10*20EpZn-8.8 | 4011000081 | 22 |
| 12 | Washer GB97.1-10EpZn-300HV | 4015000162 | 25 |
| 13 | Nut QC339-M10EpZn-8 | 4014010060 | 3 |
| 14 | Right outrigger brace | 27340103631 | 1 |
| 15 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 3 |
