LGMG Off-Highway Dump Truck 2022 – Hydraulic lifting system – M1601-2716011599.S1I
Category: 2022 > Off-Highway Dump Truck > MT96L > M096LW3A0M153
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Frame bracket（LH） | 4120710300 | 1 |
| 2 | Bolt QC340-M18*1.5*60EpZn-10.9 | 4011011616 | 16 |
| 3 | Trimmed gasket | 27160106411 | 1 |
| 4 | Trimmed gasket | 27160106421 | 1 |
| 5 | Trimmed gasket | 27160106431 | 1 |
| 6 | Limit valve | 4120001018 | 1 |
| 7 | Lifting valve | 4120002439 | 1 |
| 8 | Bolt GB5782-M12*65EpZn-8.8 | 4011000261 | 3 |
| 9 | Washer GB97.1-12EpZn-300HV | 4015000168 | 11 |
| 10 | Nut GB6170-M12EpZn-8 | 4013000011 | 13 |
| 11 | Lifting cylinder 4TG-F196*5060ZZ-02 | 4120708553 | 1 |
| 12 | Straight joint 1CH-30-33 | 4120001887 | 1 |
| 13 | Combination joint LGB143-03019 | 4041001262 | 2 |
| 14 | PLATE | 27150114221 | 1 |
| 15 | Bolt GB5783-M12*40EpZn-8.8 | 4011000091 | 4 |
| 16 | Hydraulic oil tank bracket assembly | 27160108901 | 2 |
| 17 | Hydraulic oil tank assembly | 27160116562 | 1 |
| 18 | Oil return pipe | 27160125681 | 1 |
| 19 | BUSHING LGB302-70*65B3 | 4043015519 | 2 |
| 20 | Washer GB1230-18EpZn-45 | 4015010219 | 14 |
| 21 | Nut GB6185.1-M18flZnyc-12-480 | 4013010321 | 14 |
| 22 | Bolt GB5782-M18*65flZnyc-12.9-480 | 4011010912 | 14 |
| 23 | PLATE | 27160114832 | 1 |
| 24 | High pressure hose -1650 | 27160105702 | 1 |
| 25 | Straight joint LGB120-03633 | 4041000577 | 2 |
| 26 | O-ring LGB168-12931 | 4041000765 | 2 |
| 27 | Hose | 27160112541 | 1 |
| 28 | JOINT LGB143-03625 | 4041001211 | 2 |
| 29 | O-ring GB3452.1-32.5*2.65G | 4030000276 | 1 |
| 30 | Nipple | 27160120241 | 1 |
| 31 | Pipe | 27160113251 | 1 |
| 32 | Bracket | 27160100061 | 1 |
| 33 | Nut GB6177.2-RLM18*1.5EpZn-10 | 4013010546 | 16 |
| 34 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 2 |
| 35 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 36 | Nut GB6170-M10EpZn-8 | 4013000007 | 2 |
| 37 | Pneumatic valve mounting kit | 4120001024 | 1 |
| 38 | Control air valve | 4120001017 | 1 |
| 39 | Bolt GB16674.1-M6*12EpZn-8.8 | 4011010234 | 3 |
| 40 | Pipe | 27160115691 | 1 |
| 41 | Flange fittings | 27150109871 | 1 |
| 42 | O-ring GB3452.1-37.5*3.55G | 4030000029 | 1 |
| 43 | Split flange LGB117-312551 | 4041000027 | 1 |
| 44 | Flange joint | 27150121531 | 1 |
| 45 | Bolt GB16674.1-M10*30EpZn-8.8 | 4011000475 | 4 |
| 46 | Vertical nipple | 27130111131 | 2 |
| 47 | Copper washer 10 | 27100101091 | 2 |
| 48 | Combination joint LGB143-01205 | 4041010126 | 1 |
| 49 | Pipe | 27160113241 | 1 |
| 50 | PIPE | 27400104391 | 1 |
| 51 | GUARD | 27160106271 | 1 |
| 52 | Bolt GB5782-M16*120EpZn-10.9 | 4011000622 | 2 |
| 53 | Bolt GB5782-M16*110EpZn-10.9 | 4011000730 | 2 |
| 54 | Tube | 27160109731 | 2 |
| 55 | Bracket | 27160121391 | 1 |
| 56 | Nut GB6185.1-M16EpZn-10 | 4013010136 | 4 |
| 57 | Bracket | 27160121401 | 1 |
| 58 | Grease nipple JB7940.1-M10*1 | 4030000065 | 4 |
| 59 | Butter nozzle cap JXHF-00006 | 4120000015 | 4 |
| 60 | Frame bracket（RH） | 4120710299 | 1 |
