LGMG Off-Highway Dump Truck 2022 – Mid axle assy PX – E0700-2707010555
Category: 2022 > Off-Highway Dump Truck > CMT66 > C0660W3E0A016
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Right support | 27070103891 | 1 |
| 2 | PIN | 27070103491 | 4 |
| 3 | Plate | 27070103841 | 2 |
| 4 | Mid axle assy PX25T（i=16.92） | 4110705467 | 1 |
| 5 | Left support | 27070103881 | 1 |
| 6 | Middle axle left spring seat | 27070103861 | 1 |
| 7 | Locating pin | 27070101441 | 1 |
| 8 | Seat | 27120117361 | 1 |
| 9 | Bolt m24*2*60 | 27070103901 | 8 |
| 10 | The bridge right spring seat | 27070103871 | 1 |
| 11 | Bolt m24*2*250 | 27070103911 | 8 |
