LGMG Off-Highway Dump Truck 2022 – Oil filling connection assy – A0100-2701011864
Category: 2022 > Off-Highway Dump Truck > CMT96 > C0960WF62
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Asbestos plate | 27010113631 | 1 |
| 2 | No longer used | 4019010217 | 4 |
| 3 | Bolt GB5783-M10*35EpZn-8.8 | 4011000085 | 2 |
| 4 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 2 |
| 5 | Bolt GB5783-M12*30EpZn-8.8 | 4011000089 | 2 |
| 6 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 2 |
| 7 | Bolt GB5782-M10*90EpZn-8.8 | 4011000053 | 2 |
| 8 | Washer GB97.1-10EpZn-300HV | 4015000162 | 4 |
| 9 | Connecting pipe | 27010111231 | 1 |
| 10 | PLATE | 27010117541 | 1 |
| 11 | PLATE | 27010118652 | 1 |
| 12 | FIRST BEAM ASSEMBLY | 27010118622 | 1 |
| 13 | RIGHT CONNECT PLATE ASSEMBLY | 27010118631 | 1 |
| 14 | RIGHT CONNECT PLATE | 27010118611 | 1 |
| 15 | Rubber block | 27010113511 | 2 |
| 16 | Plate | 27010113521 | 1 |
| 17 | Plate | 27010113531 | 1 |
| 18 | Bolt GB5782-M6*30-8.8 | 4011000712 | 4 |
