LGMG Off-Highway Dump Truck 2022 – Oil radiator – A0300-2703013935

Category: 2022 > Off-Highway Dump Truck > CMT106 > C1060W3E0A007

No.	Part Name	Part Number	Qty
1	Plate	27030122771	1
2	Ubolt	27030120641	6
3	Washer GB96.1-8EpZn-300HV	4015000256	6
4	Nut GB6170-M8EpZn-8	4013000033	26
5	Pipe	27030139211	1
6	Pipe	27030122741	1
7	Pipe	27030139261	1
8	Pipe	27030122751	1
9	Pipe	27030139241	1
10	Plate	27030127731	1
11	Pipe	27030121541	4
12	WITHIN BEAM	27030112491	2
13	RIGHT CARLING	27030112501	3
14	Oil raditor assembly	27030122911	1
15	Support	27030139251	1
16	Support	27030122821	1
17	Pipe clamp LGB167-0952	4041000800	3
18	Cushion sleeve LGB123-1060	4041000866	5
19	Bolt GB5783-M8*25EpZn-8.8	4011000106	4
20	Bolt GB5783-M10*30EpZn-8.8	4011000084	2
21	Washer GB97.1-8EpZn-300HV	4015000072	4
22	T-bolt clamp φ68-φ76	4190707306	16
23	Nut GB6185.1-M8EpZn-8	4013010118	4
24	Bolt GB5783-M10*25EpZn-8.8	4011000082	1
25	Washer GB97.1-10EpZn-300HV	4015000162	19
26	Nut GB6185.1-M10EpZn-8	4013010119	19
27	Bolt GB5782-M10*45EpZn-8.8	4011000451	8
28	Pipe ⅱ	27030118751	5
29	90°Elbow CX31-1503602	4110001125	2
30	Adapter	4110001033	3
31	45°Joint CX31-1503601	4110001126	3
32	Oil cooler inter pipe	4110001944	1
33	Pipe	27030139221	1
34	O-ring	4110001036	4
35	Bolt GB5782-M10*110EpZn-8.8	4011000797	2
36	Support	27030139271	2
37	Pipe clamp LGB167-0846	4041010082	2
38	Oil cooler pipe	4110702394	1
39	Plate	27030106761	1
40	Rubber plate	27030133051	2
41	Bolt GB5782-M10*90EpZn-8.8	4011000053	2
42	CUSHION SLEEVE LGB123-0846	4041001636	2
43	Bolt GB5783-M10*35EpZn-8.8	4011000085	2
44	Pipe	27030121391	1
45	Pipe	27030122951	1
46	Support1	27030122671	1
47	Pipe	27030139231	1
48	Support2	27030122681	1
49	Support3	27030122691	1
